Channels

Es’hail-2 Channels

Provider Channels Frequency (MHZ) D/L Polarization Symbol Rate (Msps) Modulation, Coding & FEC Genre
Qatar R Quran Qatar R Quran 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
Qatar Oryx Radio Qatar Oryx Radio 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
Qatar Urdu Radio Qatar Urdu Radio 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
ALKASS ONE HD ALKASS ONE HD 10770 V 27.5 DVB-S2. 8PSK 3/4 HD
ALKASS TWO HD ALKASS TWO HD 10770 V 27.5 DVB-S2. 8PSK 3/4 HD
ALKASS FOUR HD ALKASS FOUR HD 10770 V 27.5 DVB-S2. 8PSK 3/4 HD
AlKass Radio 01 AlKass Radio 01 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
Qatar Radio Quran 2 Qatar Radio Quran 2 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
Hola Qatar Hola Qatar 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio
Qatar QBS Radio Qatar QBS Radio 10770 V 27.5 DVB-S2. 8PSK 3/4 Radio

Total: 133 Channels

6 Out of 14

Satellite Data

Setup
Guide

Follow the steps listed in this step-by-step Setup Guide in order to be able to receive TV channels from Es’hailSat’s satellites.

SET UP GUIDE STEP

01

Select Es’hail-1 or Es’hail-2 satellite from the satellite selection menu, or any satellite name on 25.5° or 26° East / Ku -Band (depending on your set-top-box model and software version).

See sample
SET UP GUIDE STEP

02

Viewer can Search manually by using numeric buttons on the remote control: the Frequency, Symbol Rate, Polarization & FEC for each transponder parameters, can be selected from the available list in the setup box, and press search ( Network search: Disabled) Once completed, the viewer may select another transponder parameters, and proceed till the end of the list.

Alternatively, Viewer can easily download all Es’hail-1 and Es’hail-2 channels by using one frequency, Which are anchor frequencies for Es’hailsat satellites on 25.5° / 26° East, and by following Step#3.

See sample
SET UP GUIDE STEP

03

Enter one of the below frequencies by using numeric buttons on the remote control: the Frequency, Symbol Rate, Polarization & FEC for each transponder parameters, or select it from the setup box list if available.

Txp Freq. Polarization Symbol Rate FEC
10730 Horizontal 30000 3/4
11310 Vertical 30000 2/3
11350 Horizontal 30000 3/4

  1. Set “Scan Mode” into All Channels
  2. Set “Network Search” into Enable or choose YES
  3. Set “PID Search” into Auto

See sample
SET UP GUIDE STEP

04

Enjoy! Once search is completed, press save if requested by your setup Box, then Enjoy!
You are receiving all Es’hail-1 and Es’hail-2 Direct-to-Home TV channels.

See sample
